Feature:
1. ♦ High Speed Barcode Scanning: Equipped with 300,000 All Stations CMOS sensors, it can cope with various scanning angles and irregular barcodes, and supports screen codes. A pedestal with OLED screen to display the battery power and connection in real time. Widely used in supermarket, retail, library, logistics, warehouse, etc.
2. ♦ Wireless BT+2.4G Connection: Support BT and 2.4G wireless and USB wired to connect. Plug and play, free drive. Compatible for Android, Linux, Mac, Windows XP 7 8 10, etc. Support 0 80 meters 2.4Gz wireless connecting distance. Simply connect it to your device using the USB interface, and you\u0027re ready to start scanning right away. No complicated installation or configuration required.
3. ♦ Optional Scanning Mode \u0026 Storage Mode: 3 scanning modes: manual trigger mode, auto scanning mode and continuous scanning mode. Flexible mode with hand free and handheld operation. In addition, supports storage of up to 10000 barcodes.
4. ♦ Strong Decoding Capacity: 1D (EAN13, EAN 8, UPC A, UPC E0, UPC E1, Code128, Code39, Code93, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, CodeBar, MSI, RSS 14, RSS Ltd, RSS Exp, Standard 2 of 5, Plessey, ChinaPost 25, GS1 Composite, etc). 2D ( QR Code, Data Matrix (DM), PDF417, Han Xin, PDF417, QRCode, MaxiCode, Aztec Code, Code16K, etc)
5. ♦ Reliable Performance: Built to withstand the demands of daily use. Its durable construction ensures long lasting performance, while its ergonomic design provides comfort during extended scanning sessions. Built in 2000mAh rechargeable battery, full charge allows 24hrs using time and Standby time up to 10 days.
Specification:
Specification:
Model: W2 L
Scan mode: Key trigger auto sensing continuous scanning
Communication interface: USB keyboard
USB COM virtual serial port
Wireless
communication distance: Wireless
2.4G: 0 80m (open environment); BT: 0 2 0 m(open environment).
Prompt mode: Buzzer, LED light
, vibration
motor
How it is set up: Manually scan the setting code in turn and press the key to set
Housing material: ABS+PC
Cable standard: USB 1m
Exterior size: 157mm*70mm*112mm(product);128 mm*81 mm*89mm(pedestal)
Weight: 179.2g (net weight).
Sensors: 300,000 All Stations CMOS
Resolution: 640x480
Light
source: White LED
Scan angle: + 60 degrees , + 60 degrees , 360 degrees (elevation, declination, rotation).
Scan rate: 120 fps
Field of view: 48 degrees (H) x 30 degrees (V)
Printing contrast: Minimum 15percent .
Decoding kind
1D: EAN 13, EAN 8, UPC A, UPC E, ISSN, ISBN, CodaBar, Code 128, Code93, Interleaved 2 of 5, Industrial 2 of 5, GS1 Databar(RSS
) , Code 39, Code 11, MSI
Plessey,etc
2D: QR Code, DM, PDF417, Micro QR, Aztec, etc., support mobile screen reading
Minimum resolution: 1D code 3MIL; QR code 5MIL
Input voltage: DC 5V+ 10percent
Current Working: 350 mAh; Standby: 130 mAh
Battery
: 2000mAh lithium ion battery
Charging time: 4 hours
Battery
life: 10 days (standby), 24 hours (working: scan every 5 seconds).
.
Package List:
1 x Barcode Scanner
1 x Cradle
1 x USB Cable
